Summary

MicroFit MFHLP31282 Replaces the Hy-Pro HP16DNL1425MV

HP16DNL1425MV
HP16DNL1425MV
Representative product image Product image feedback

MicroFit® UltraGen III MFHLP31282 Pressure Filter | Replaces the Hy-Pro HP16DNL1425MV

Brand: MicroFit
Description

The MICROFIT® UltraGen III MFHLP31282 is the MICROFIT® approved replacement to the Hy-Pro HP16DNL1425MV. Engineered and manufactured in Great Britain the MFHLP31282

Price Match
$114.00
2.87 lbs
0.06 ft³
268 pcs
United Kingdom
8421.99.90
1.52 lbs
0.138 ft³
268 pcs
United States
8421.29.80.90
1.3 lbs
0.06 ft³
268 pcs
Italy
8421.99.90
Shipping Terms

Description

The MICROFIT® UltraGen III MFHLP31282 is the MICROFIT® approved replacement to the Hy-Pro HP16DNL1425MV. Engineered and manufactured in Great Britain the MFHLP31282

Specification

StylePressure Filter
MediaGlass Fiber
Efficiency 120µ @ β200
Efficiency 222µ @ β1000
Outer Diameter 2 11/16"
Inner Diameter 1 3/8"
Length 14"
Δ Collapse Pressure 290.1 psi
Seal MaterialViton
Temperature Range -10 - +250°F
Default Brand Logo

Same Fit-Form & Function

As the Genuine Hy-Pro HP16DNL1425MV

ISO Icon

Inspected to ISO 9001:2015

See Our Certification
Returns Icon

Free 45-Day Returns

Return Policy
Warranty Icon

1 Year Manufacturer Warranty

Our Warranty
Specification
Efficiency 1
The efficiency of the element is shown using the Micron (µ) and Beta (β) ratings. The micron rating indicates the size of the particle being filtered and the beta rating the efficiency, calculated as 1/β.
E.g. a rating of β200 will be 99.5% efficient whereas β1000 would be 99.9%.
20µ @ β200
Efficiency 2 22µ @ β1000
Style Pressure Filter
Outer Diameter 2.72 in
Inner Diameter 1.35 in
Length 13.98 in
Media Type Glass Fiber
Flow Direction OUT-IN
Thread
Bypass Pressure

Bypass pressure relieve build-up of pressure within the system and allows medium to bypass the element when pressure increases and reaches a sufficient level.

Collapse Pressure 290 PSI
Seal Viton
Temperature Range -10 - +250°F
