Stauff NL-160-E-10-B/4 Replaces the Stauff NL160E10B
Stauff NL-160-E-10-B/4 DIN Pressure Filter | Replaces the Stauff NL160E10B
NL-160-E-10-B/4
Stauff
Stauff NL160E10B
Stauff
Stauff NL160E10B
Brand:
Stauff
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 159 Sealing: NBR, β ratio >200
Regular price
$176.00
Unit price
per
6 pcs
Germany
8421.99.90
2.33 lbs
0.034 ft³
6 pcs
United Kingdom
8421.99.90
1.15 lbs
0.042 ft³
6 pcs
France
8421.99.90
1.06 lbs
0.034 ft³
6 pcs
Italy
8421.99.90
1.1 lbs
0.072 ft³
6 pcs
United States
8421.29.80.90
1.16 lbs
0.057 ft³
6 pcs
Germany
8421.23.00
6 pcs
Germany
8421.99.90
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 159 Sealing: NBR, β ratio >200Specification
| Style | DIN Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 3 1/16" |
| Inner Diameter | 1 5/8" |
| Length | 6 3/16" |
| Δ Collapse Pressure | 304.6 psi |
| Seal Material | Nitrile |
| Temperature Range | -20 - +210°F |
Stauff Product
Genuine Stauff NL-160-E-10-B/4
Inspected to ISO 9001:2015
