Stauff NL-160-E-10-B/4 Replaces the Stauff NL160E10B4

Stauff NL-160-E-10-B/4 Replaces the Stauff NL160E10B4
NL-160-E-10-B/4
Stauff
Stauff NL160E10B4
Stauff
Stauff NL160E10B4
Brand:
Stauff
Sort by:
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 159 Sealing: NBR, β ratio >200
$178.00
Shipped Monday, June 30
Fastest delivery Tuesday, July 1
Fastest delivery Tuesday, July 1
UNITS | PER UNIT |
---|---|
2 - 4 | $174.44 |
5 - 9 | $170.88 |
10 - + | $167.32 |
1.14 lbs
8421.99.90
Germany
Description
Replacement Filter Element for Medium-Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 79,8 Inner Diameter (mm): 40,2 Length (mm): 159 Sealing: NBR, β ratio >200Specification
Style | DIN Pressure Filter |
Efficiency 1 | 10µ @ β200 |
Efficiency 2 | 12µ @ β1000 |
Outer Diameter | 3.07 in |
Inner Diameter | 1.59 in |
Length | 6.18 in |
Media | Glass Fiber |
Flow Direction | OUT-IN |
Δ Collapse Pressure | 305 PSI |
Seal Material | Nitrile |
Temperature Range | -20 - +210°F |
Genuine Product
Find out more
Stauff Product
Genuine Stauff NL-160-E-10-B/4

Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
