Stauff NR-100-E-10-B/4 Replacement DIN Return Filter
Stauff NR-100-E-10-B/4 Replacement DIN Return Filter
NR-100-E-10-B/4
Stauff
Stauff
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 58 Inner Diameter (mm): 32,2 Length (mm): 249 Sealing: NBR, β ratio >200
Brand:
Stauff
$144.00
Delivered Thursday, March 20
| UNITS | PER UNIT |
|---|---|
| 2 - 4 | $141.12 |
| 5 - 9 | $138.24 |
| 10 - + | $135.36 |
0.79 lbs
8421.99.90
Description
Replacement Filter Element for Return-Line Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 58 Inner Diameter (mm): 32,2 Length (mm): 249 Sealing: NBR, β ratio >200Specification
| Style | DIN Return Filter |
| Efficiency 1 | 10µ @ β200 |
| Efficiency 2 | 12µ @ β1000 |
| Outer Diameter | 2.28 in |
| Inner Diameter | 1.27 in |
| Length | 9.8 in |
| Media | Glass Fiber |
| Flow Direction | OUT-IN |
| Δ Collapse Pressure | 145 PSI |
| Seal Material | Nitrile |
| Temperature Range | -20 - +210°F |
Genuine Product
