Stauff SP-045-E-10-V/4 Replaces the Stauff SP-045-E-20-V/4
Stauff SP-045-E-10-V/4 Pressure Filter | Replaces the Stauff SP-045-E-20-V/4
SP-045-E-10-V/4
Stauff
Stauff SP-045-E-20-V/4
Stauff
Stauff SP-045-E-20-V/4
Brand:
Stauff
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 80 Inner Diameter (mm): 43,5 Length (mm): 114 Sealing: FPM, β ratio >200
Regular price
$95.00
Unit price
per
Germany
8421.99.90
1.9 lbs
0.025 ft³
United Kingdom
8421.99.90
0.88 lbs
0.031 ft³
France
8421.99.90
0.86 lbs
0.025 ft³
Italy
8421.99.90
Description
Replacement Filter Element for Pressure Filters Micron Rating: 10 µm Material: Inorg. Glass Fibre Outer Diameter (mm): 80 Inner Diameter (mm): 43,5 Length (mm): 114 Sealing: FPM, β ratio >200Specification
| Style | Pressure Filter |
| Media | Glass Fiber |
| Efficiency 1 | 20µ @ β200 |
| Efficiency 2 | 22µ @ β1000 |
| Outer Diameter | 3 1/16" |
| Inner Diameter | 1 11/16" |
| Length | 4 9/16" |
| Δ Collapse Pressure | 304.6 psi |
| Seal Material | Viton |
| Temperature Range | -10 - +250°F |
Stauff Product
Genuine Stauff SP-045-E-10-V/4
Inspected to ISO 9001:2015
See Our Certification
Free 45-Day Returns
Return Policy
